Die locking force

6800 KN

Space between tie bars

800*800 MM

Tie bar diameter

Φ 160 MM

Die thickness(Min-Max)

350~900 MM

Locking stroke

650 MM

Ejection stroke

160 MM

Ejection force

315 KN

Injection force

610 KN

Injection position

0 、 -250 MM

Plunger diameter

70 MM

80 MM

Injection weight

4.7 KG

6.2 KG

7.7 KG

Casting pressure (Intensifg.)

158 Mpa

121 Mpa

95 Mpa

Casting area

430 CM²

561 CM²

715 CM²

Max.Casting area (40Mpa)

1700 CM²

Plunger penetration

280 MM

Casting flange diameter

Φ150 MM

Height of pressure chamber flange

15 MM

Injection stroke

650 MM

Dry cycle

14 S

System working pressure

14 Mpa

Motor power

37 KW

Oil tank capacity

1250 L

Machine weight

31200 KG

Machine dimensions(L*W*H)

8*2.3*3.2 M
