Forging station

6 NO.

Forging force

148,000 KGS

Max cut-off dia.

Φ 18 MM

Max cut-off length

240 MM

Speed range

55-90 PCS/MIN

P.K.O stroke

40 MM

K.O.Stroke

210 MM

Main slide stroke

320 MM

Main moto

45 KW

Cut-off-die size

Φ 58* 80L MM

Punch die size

Φ 60* 130L MM

Main die size

Φ 94* 240L MM

Die pitch

110 MM

Machine dimension(L*W*H)

620*310*250 CM

Machine weight(Approx)

42,000KGS

Max forging dia on head

Φ 25 MM

Normal bolt size

8-12.7MM

Shank length of blank

40-200 MM
